Thermawall Series-51mm平板可单件设计，最终完成集保温性能，湿度控制和美观于一体的完整外墙设计。
Thermawall Series 51mm Flat panel provides outstanding aesthetics and value, along with maximum thermal performance and moisture control – all in a single component.
◎面板：采用50mm厚金属岩棉复合板（外板0.7mm，镀铝锌基板，双面镀锌含量150g/㎡,屈服强度不低于345MPa。
Outside panel : 50mm metal composite panel(outside panel 0.7mm, galvanized base plate, Zinc content 150g/㎡,yield strength no less than 345MPa.
◎底板：采用镀铝锌钢板，厚度为0.5mm，PE涂层，屈服强度为不低于330MPa,采用镀铝锌基板。
Base panel : 0.5mm galvanized steel plate with PE coating,yield strength no less than 330MPa, galvanized base plate.
◎中间层：填满容重120kg/m3岩棉，导热系数0.046w/(m.k),燃烧性能A2级不燃材料（金属岩棉复合板的构造做法及相关技术要求需符合国家建筑标准设计图集08J925-3的相关要求），采用螺钉连接。面板间缝隙采用泛水收边条及硅胶填嵌。
Core material: Core material: filled with 120kg/m3 Rockwool, coefficient of thermal conductivity 0.046w/(m.k), A2 level incombustible material( this metal composite panel meet nation building standard design requirements for component structure and relevant technique ). Gap between panels is filled with flashing edge and silica gel.
可水平或竖直方向安装。
Can be installed horizotally or vertically.
材质
● G90镀锌基材,铝镁锰合金，钛锌基材，铜基材，阳极氧化基材
尺寸
● 标准厚度50mm/75mm/100mm/150mm
● 也可选择其他型号配置，请向斯迪莱特公司咨询
饰面处理
● 外表面-无方向性压花表面，亦可平板或条纹板
● 内表面-无方向性压花表面，宽条效果
接缝处理
● 垂直方向-双榫槽接口
● 水平方向-等压雨屏设计，13mm标定尺寸接缝-标准型
板材宽度
● 标准型-1米
● 定制-宽度可选
板材长度
● 平板光面-最大8.0米
● 压花条纹面-最大11.0米
● 压花面-最大11.0米
● 光滑条纹面-最大11.0米
● Duracast 饰面-最大8.0米
横缝深度
● 4mm-150mm可调
SUBSRATES
● G90 Galvanized base material,Aluminium,anodizing,zinc,copper
SUBSRATES
● Standard thickness 50mm/75mm/100mm/150mm
● Optional gages available – consult STEELITE
● Optional stainless steel face sheet, 304 stainless steel, 22 or 20 gage, smooth, embossed or striated
SURFACE FINISH
● Exterior - Non-directional embossed flat, striated or variable striated
● Interior- Non-directional embossed planked flat
JOINERY
● Vertical oriented panel – Double tongue-and-groove, 1/8” [3mm] nom. joint – standard
● Horizontal oriented panel – Rainscreen, pressure-equalized and drainable joinery, 1/2” [13mm] nom. joint – standard
PANEL WIDTH
● Standard-1meter
● Custom-made
PANEL LENGTH
● Smooth – 8.0m max.
● Embossed striated – 11.0m max.
● Embossed – 11.0m max.
● Smooth striated-11.0m max.
● Duracast – 8.0m max.
Variable reveals
● 4mm-150mm
